LSZH is the abbreviation of "Low Smoke Zero Halogen", which refers to flame retardant materials that do not contain halogens (such as chlorine, bromine, iodine, etc.), and is used to indicate non-halogenated flame retardant wirewound sheath materials. The material has excellent fire safety characteristics of low smoke, low toxicity, and low corrosion. When a fire occurs, LSZH wires will not produce toxic smoke and other harmful organic compounds, which are harmless to human health. Therefore, LSZH wires are widely used in places where personal safety must be highly guaranteed, such as subways, airplanes, large exhibition halls, etc.
Any type of network cable, such as Category 5e network cable, Category 6 network cable, Category 7 network cable, etc., can choose low smoke zero material as the outer sheath.
Product material: 99.95% oxygen-free copper core, imported high-density PE insulation layer, brand new environmentally friendly flame retardant/LSZH outer skin
Wire size: (n*n*AWG) 2 cores × 4 pairs × 24AWG
Copper core diameter: 0.40mm/0.45mm/0.48mm/0.50mm/0.57mm, etc.
Product specifications: 305 meters/box, easy-to-pull box
Quality inspection requirements: Pass Fluke 90-meter link test
Product certification: Passed the certification of the Information Industry Data Communication Product Quality Supervision and Inspection Center
Using temperature: -20~60℃
Flame retardant grade: VW-1, CM grade, IEC 60332-1-2, GB/T 18380.12-2008
Quality assurance: 20 years
